Place of Origin | CHINA |
Brand Name | LIANGRU |
Certification | ISO |
Model Number | 155M |
640 725 819 9141018 Textile High Nickel Screen Printing 25M Screen Mesh
Repeat(mm) | 640 725 819 914 1018 | ||
Mesh | Thickness(μm) | Open Area(%) | Hole Diameter |
80 | 110-115 | 16-18 | 105 |
100 | 105-110 | 15-17 | 74 |
125 | 100-105 | 14-16 | 79 |
Production details:
Rotary Nickel Screen, circumference (e.i.640,819,914,1018mm), mesh(from 14 to 185),length(from 1450 to 3500mm).
Rotary nickel screen: we can supply various nickel screens
a) Circumference: 640mm, 819mm, 914mm and 1018mm
b) Mesh: from 14 to 185
c) Length: from 1450mm to 3500mm
d) Characteristic of uniform transparency, high open area, good toughness and elasticity,can be used for 5~7 times repeatedly, saving dyestuff, bear high temperature
e) Suitable for printing on cloth and other fibers in textile industries and wallpaper printing industries
Advantage:
• More tough and tensile, safely operation and multiple use
• orderliness and accurate screen caves, good dye output and osmotic function
• Good symmetrical, good conglutination function of photosensitive medicament
rotary screen printing
silk screen printing fabric printing T shirt printing digital printing
high tension polyester silk screen printing mesh
T- shirt screen printing monofilament polyester bolting cloth
Monofilament polyester bolting cloth (printing mesh) Silk screen printing mesh
Competitive Advantage:
Open area up to 18% ,there is no factory in china can make it except our factory,it help smooth throughout of dyestuff paste, so that printing speed and efficiency of printing machine can be ascended,experiments have proved that up to 19% of paste volume can be saved at multiple printing mills around the world.
Use 5-6 times stripping by water jet or LEN,by collecting the data from thousand of experiments.Our screen also SULFUR-FREE and with excellent brittleness,a convenient way to test the brittleness is the so-called "lighter test": a piece of screen sample burnt by lighter flame for 10 seconds, bend the screens sample to see if it breaks at the burnt spot. our screens will not broken.
Thickness:11.5microns
Our quality is No.1 in china,even Chinese RMB paper currency also use our screen,so i am sure if you buy our screen,it absolutely will save a lot of money for your company.
Package: plywood cases or as you required
Rotary Screen Printing Standard rotary screen for textile printing:
Mesh | Thickness(μm) | Open area(%) | Hole diameter(μm) |
155 | 100-105 | 13 | 70 |
DLH=Small open area,suitable for transferprint
Product use effect:
